    250L/Min Mortar Spray Piston Mud Pump Single Acting For Wall Building

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KBW-250
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 100 Sets/Per Month
    Delivery Time : 5~8 Work Days
    • Product Details
    • Company Profile

    250L/Min Mortar Spray Piston Mud Pump Single Acting For Wall Building

    Construction Machinery Sand Mortar Spray Piston Pump Machine For Wall Building

    Slurry Pump Features:

    1. KBW-250 grouting pump is horizontal triplex reciprocating single-acting piston pump.

    2. Two different cylinder diameters, four gear speed, four displacements for different drilling hole size and hole depth.

    3. High quality pump parts, less energy consumption, less wearing parts, long service life.

    4. Flexible manipulation, easy dismantlement and move.

    Slurry Pump Application:

    1. KBW-250 grouting pump with large cylinder diameter (Φ80mm) can equip large-aperture drilling machine (1000m), and grout pump with small cylinder diameter (Φ65mm) can equip small-aperture drilling machine (1500m).

    2. KBW-250 grout pump can be used as cement grout pump in foundation treatment engineering, railway, hydraulic engineering, metallurgy, construction, geology and other industries.

    Slurry Pump Parameters:

    Model
    KBW-250 grouting pump
    Type
    Horizontal triplex reciprocating single-acting piston pump
    Stroke (mm)
    100
    Cylinder diameter (mm)
    80
    65
    Stroke frequency (min-1)
    200
    116
    72
    42
    200
    116
    72
    43
    Flow (L/min)
    250
    145
    90
    52
    166
    96
    60
    35
    Pressure (MPa)
    2.5
    4.5
    6.0
    6.0
    4.0
    6.0
    7.0
    7.0
    Volume efficiency (%)
    90
    Overall efficiency (%)
    75
    Power (kw)
    15
    Input speed (r/min)
    500
    Suction height (m)
    2.5
    Suction pipe ID. (mm)
    76
    Discharge pipe ID. (mm)
    52
    Dimensions (L×W×H) (mm)
    1750×950×950
    Weight (kg)
    550
