    Dry Mix Guniting Concrete Spray Shotcrete Machine Diesel Driven

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KPZ-5D
    Certification : CE,MA
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 100 Set/Per Month
    Delivery Time : 10~20 Work Day
    • Product Details
    • Company Profile

    Dry Mix Guniting Concrete Spray Shotcrete Machine Diesel Driven

    Diesel Driven Dry Mix Guniting Jet Spray Shotcrete Machine Prices

    Shotcrete Machine Features:

    1. KPZ Series Dry Shotcrete Machine include Electric Shotcrete Machine (KPZ-3, KPZ-4, KPZ-5, KPZ-7, KPZ-9, KCPZ), Pneumatic Shotcrete Machine (KPZ-3A, KPZ-4A, KPZ-5A, KPZ-7A, KPZ-9A), Diesel Engine Shotcrete Machine (KPZ-3D, KPZ-4D, KPZ-5D, KPZ-7D, KPZ-9D), and Mining Shotcrete Machine (PC5I, PS6I-J).

    2. KPZ-5D Diesel Shotcrete Machine are consisted of driving device, rotor assembly, air system, concrete spraying system, diesel engine etc.

    3. KPZ-5D Diesel Shotcrete Machine have advanced technology, rational structure, convenient operation, stable performance and long service life.

    Shotcrete Machine Application:

    1. KPZ-5D Diesel Shotcrete Machine can be used for dry or half wet concrete spray construction.

    2. KPZ-5D Diesel Shotcrete Machine are widely used in the tunnel, culvert, subway, slope reinforcement, hydroelectric works, underground works and high-methane laneway of coal mine etc.

    Shotcrete Machine Parameters:

    ModelKPZ-5D Diesel Engine Shotcrete Machine
    Capacity4.5-5.5 m3/h
    Max. conveying dist.≤ 200m
    Suitable mixture ratiocement/sand and gravel=1:4~5
    Suitable water-cement ratio<0.4
    Max aggregate sizeφ15mm
    Spraying hose ID.φ51mm
    Operating pressure0.2~0.6Mpa
    Air consumption7~8 m3/min
    Power typeDiesel engine
    Diesel power13 KW (18hp)
    Dimensions(Length×width×height)2400×850×1200mm
    Total weight880kg
    Dry Mix Guniting Concrete Spray Shotcrete Machine Diesel Driven
