    Dry Wet Mix Blasting Shotcrete Equipment For Refractory

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KPZ-7
    Certification : CE,MA
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 100 Set/Per Month
    Delivery Time : 10~20 Work Day
    • Product Details
    • Company Profile

    Dry Wet Mix Blasting Shotcrete Equipment For Refractory

    Dry And Wet Mix Blasting Machine Wet Mix Shotcrete Machine Uae For Refractory Application

    Shotcrete Machine Features:

    1. KPZ Series Dry Shotcrete Machine include Electric Shotcrete Machine (KPZ-3, KPZ-4, KPZ-5, KPZ-7, KPZ-9, KCPZ), Pneumatic Shotcrete Machine (KPZ-3A, KPZ-4A, KPZ-5A, KPZ-7A, KPZ-9A), Diesel Engine Shotcrete Machine (KPZ-3D, KPZ-4D, KPZ-5D, KPZ-7D, KPZ-9D), and Mining Shotcrete Machine (PC5I, PS6I-J).

    2. KPZ-7 Shotcrete Machine are consisted of driving device, rotor assembly, air system, concrete spraying system, electric control box etc.

    3. KPZ-7 Dry Shotcrete Machine have advanced technology, rational structure, convenient operation, stable performance and long service life.

    Shotcrete Machine Application:

    1. KPZ-7 Dry Shotcrete Machine can be used for dry or half wet concrete spray construction.

    2. KPZ-7 Dry Shotcrete Machine are widely used in the tunnel, culvert, subway, slope reinforcement, hydroelectric works, underground works and high-methane laneway of coal mine etc.

    Shotcrete Machine Parameters:

    Model
    KPZ-7 Shotcrete Machine
    Capacity
    7m3/h
    Conveying dist. max.
    ≤200m
    Suitable mixture ratio
    cement/sand and gravel=1:4~5
    Suitable water/cement ratio
    ≤0.2~0.38
    Aggregate size max.
    φ20mm
    Conveying hose ID.
    φ57/ 64mm
    Operating pressure
    0.2~0.4Mpa
    Air consumption
    10 m3/min
    Material feeding height
    1.2m
    Motor power
    7.5kw
    Dimensions(Length×width×height)
    1520×820×1350mm
    Total weight
    900kg
