    Piston Spraying Concrete Shotcrete Pump For House Wall

    Ask Lasest Price
    Brand Name : Keming
    Model Number : KMB series
    Certification : CE, MA, ISO
    Price :
    Payment Terms : T/T, Western Union, D/A, D/P, L/C
    Supply Ability : 20 sets per month
    Delivery Time : 2-3weeks
    • Product Details
    • Company Profile

    Piston Spraying Concrete Shotcrete Pump For House Wall

    Concrete Piston Shotcreting And Spraying Concrete Shotcrete Pump For House Wall Spraying


    product description

    The piston wet spraying machine uses the thrust generated by the hydraulic pump to make the two cylinders alternately move back and forth to send the dense flow material from the conveying pipe to the mixed flow pipe. The compressed air forms a thin stream and sends it to the nozzle through the pipe. A certain proportion of accelerator is added and sprayed directly onto the spray surface of a mechanical, electrical and hydraulic three-in-one mechanical equipment.


    Advantages:


    1. Large conveying displacement and high comprehensive work efficiency.
    2. Long spray distance
    3. One machine has multiple functions, it can be used as wet spraying machine, concrete pump or mortar pump.
    4. Use key components from well-known domestic manufacturers to ensure high reliability of the equipment.
    5. The addition amount of accelerator is continuously adjustable and can be steplessly adjusted according to the shotcrete amount.
    6. Equipped with automatic lubrication system, greatly extending the life of wearing parts.
    7. Four-wheel solid tires are easy to move and easy to operate and maintain.
    8. The hydraulic oil is cooled by air cooling, which is simple and environmentally friendly.
    9. Low resilience, using wet spray technology, the resilience rate can even be reduced to less than 10%, effectively saving costs.
    10. Reduce the dust concentration beside the machine and outside the nozzle, and eliminate the harm to workers' health.


    Specification
    itemsunitparameter
    KMB-50KMB-40KMB-30KMB-20KMB-10KMB-8
    capacitym3/h50(30-34)40_25-30)30(20-25)20(15)10(8)8(6)
    Max. aggregate sizemm403020202515
    delivery pipemmDN150/DN125DN125/DN100DN125/DN100DN125/DN100DN100/DN80DN80
    Max. disthorizontalm30030030020015050
    verticalm100/80100/8080/60406020
    diesel enginekw8456444040none
    main oil pump140 double140/112 double112/80 double805040
    cylinder diameter200180140120140120
    motor powerkw554537222215/11
    out[ut pressureMpa8-138-136-85-85-83-5
