Electrical Engine KQD SeriesDrilling Rig Cement Grouting Pump For
Rock With 150mm Drilling Head
Application:
High efficiency simple Drilling Rigs are a new, highly efficient
and extensively applied open-air rock drilling equipment designed
by our company, which is extensively suitable for small and medium
sized mines and the projects such as communications, national
defense, water conservancy and stonework, in particular the rough
and rugged terrains and land forms where other drills are unable to
operate normally.
There are two kinds, drilling for soil and drilling for rock. For
the drilling head, there are several diameter, 90mm, 100mm, 150mm
and 190mm. The drilling rod have two kinds, plate type and screw
type, plate type is for rock and the screw type is for soil.
Features:
1. drilling rig tools widely used in mines,
transportation,defense,water conservancy,rock engineer, especially
rugged terrain.
2. Low center of gravity,easy to fold and to move.
3. Rotator reducer with high torque ensure operating reliable in
the case of strong vibrations or heavy duty.
4. Simple structure,easy to operate,low cost.
5. Propulsion system equipped with relief valve,adjusting
propulsion,ensure excellent performance
6. Different driven engine types,such as hydraulic and electric,and
pneumatic.
Specification:
Model Parameters | | KQD70 | KQD100A | KQF100 | KQJ100A electric | KQJ100A diesel |
| rock hardness | | F=6~20 | F=6~20 | F=6~20 | F=6~20 | F=6~20 |
| Borehole diameter | mm | 50~80 | 68~130 | 68~130 | 68~130 | 68~130 |
| Borehole depth | m | ≥15 | ≥20 | ≥20 | ≥20 | ≥20 |
| One-time advance length | mm | 1000 | 1000 | 1000 | 1000 | 1000 |
| Swing speed | r/min | 90 | 90 | 110~160 | 0~70 | 0~70 |
| Air consumption | m3/min | ≥3.5 | ≥7 | ≥12 | ≥7 | ≥7 |
| Working air pressure | Mpa | 0.5~0.7 | 0.5~0.7 | 0.5~0.7 | 0.5~0.7 | 0.5~0.7 |
| Cylinder diameter | mm | 90 | 140 | 140 | 50 | 50 |
| Max. lifting force | N | 4200 | 7000 | 7000 | 15000 | 15000 |
| Max. advance force | N | 3500 | 5000 | 5000 | 4500 | 4500 |
| Whole weight | kg | 175 | 260 | 260 | 260 | 260 |
| Driving power | kw | 3 | 4 | 4 | 7.5 | 12.1 |
Certification:
In July 2009, the company passed the ISO9001:2008 Quality
Management System Certification.
In October 2010, the company was entitled as the “Henan Provincial
High-tech Enterprise”.
In 2013, the new wet shotcrete technology was reward the second
prize of
Henan Provincial S&T Progress Award.
In December 2014, the brand “KEMING” was awarded the “Henan
Provincial Famous Trademark”.
In October 2016, “KEMING” series products have been certified by CE
Certification.
Company information:
Henan Coal Science Research Institute Keming Mechanical and
Electrical Equipment Co. , Ltd. (the former Keming Mechanical and
Electrical Department of Henan Coal Scientific Research Institute)
is a holding subsidiary of Henan Coal Scientific Research Institute
Co., Ltd.
Our company is dedicated to the research and development,
production and sales of shotcrete machine, grouting pump, and
complementary products. Up to now, we have developed more than 50
kinds of products, covering spraying machines, pumps and other
series of products.
Achievements: Our company has obtained more than 20 national invention patents
and utility model patents, more than 10 scientific and
technological achievements appraisal awards, 8 awards from China
National Coal Association and Department of science and technology
of Henan province, and the second prize of Henan Provincial S&T
Progress Award.
Business Scope: As a comprehensive high-tech enterprise, our company is engaged in
the research and production of mining machinery, engineering
machinery and supporting equipment for underground engineering, as
well as environment protection, chemical industry, inspection and
testing of mining equipment, research and production of mechanical
and electrical products, technology and finance, management and
technology consulting service, and other industries.
Cooperate Culture:
Enterprise Spirit: Devotion, responsibility, innovation, excellence
Service Concept: Serve consumers and satisfy consumers
Business Philosophy: Cultivate excellent talent, invent superior product, offer perfect
service
Enterprise Vision: Lead the machinery manufacturing industry, be an outstanding
listed company
Corporate responsibility:
Be responsible for the society, operate lawfully, contribute to the
society
Be responsible for the shareholder, increase the assets value,
stabilize the returns
Be responsible for the customer, service-oriented, integrity-based
Be responsible for the staff, make career plan, live and work in
peace
Exhibition:
Bauma Shanghai 2018
FAQ:
1. Q:How to pay for this order?
A:Generally, TT, 30% deposit 70% before shipment； L/C at sight
(high bank charge, not suggest, but acceptable);100% TT in advance
(especially for small amount and spare parts etc.)
2. Q:How to place an order?
A:Both online order and offline order are acceptable.
3. Q:How about the package?
A:We have fumigation-free wooden case to protect the machine from
damage during the long-distance delivery.
4. Q:What is the lead time?
A:1 week for sample model, 2~3 weeks for customized model. It
depends for mass production.
5. Q:What should we do if there are some problems with the machine?
A:You can refer to the Operate Instruction or call our 24-hour
service hotline. Also, our engineers are available to service
overseas.
6. Q:Do i need technical skills to operate this machine?
A:Yes. Please read the Operation Instruction for some basic
technical skills. And, we provide online and onsite technical
training if necessary.
