    Convenient Operation Concrete Shotcrete Machine 600mm For Culvert Construction

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KEMING Shotcrete Machine Set with Feeder
    Certification : CE, MA
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 100 Sets/Per Month
    Delivery Time : 5~8 Work Days
    • Product Details
    • Company Profile

    Convenient Operation Concrete Shotcrete Machine 600mm For Culvert Construction

    Convenient Operation KEMING Shotcrete Machine Set with Feeder for Culvert Construction

    KEMING Shotcrete Machine Set with Feeder Information:

    1. KEMING Shotcrete Machine Set has simplified operation,automatic feeding, convenient maintenance and cleaning.

    2. KEMING Shotcrete Machine Set has fewer dusts, reliable performance, long conveying distance.

    3. KEMING Shotcrete Machine Set includes concrete spraying machine, grout making machine, delivery pump and auxiliary piping system.

    KEMING Shotcrete Machine Set with Feeder Technical Parameters:

    Items

    Unit

    Technical parameters

    Model

    JPS7I-L Shotcrete Machine

    Capacity

    m3/h

    5~7

    Conveying dist.

    m

    70/20

    Suitable water and cement ratio

    cement/gravel=1:3-5

    Aggregate size max.

    mm

    ≤20

    Conveying pipe ID.

    mm

    φ50

    Operating pressure

    MPa

    0.2~0.4

    Air consumption

    m3/min

    7-8

    Material feeding height

    m

    1.2

    Motor power

    kw

    5.5(feeder)/7.5(main motor)

    Voltage

    V

    380/660 or 660/1140

    Machine gauge

    mm

    600(900)

    Dimensions (Length×width×height)

    mm

    2930×1152×1620

    Total weight

    kg

    1250


    KEMING Shotcrete Machine Set with Feeder Application:

    1. KEMING Shotcrete Machine Set has simplified operation,automatic feeding, convenient maintenance and cleaning.

    2. KEMING Shotcrete Machine Set has fewer dusts, reliable performance, long conveying distance.

    3. KEMING Shotcrete Machine Set includes concrete spraying machine, grout making machine, delivery pump and auxiliary piping system.

    Convenient Operation Concrete Shotcrete Machine 600mm For Culvert Construction


    Company Information:

    Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. (the former Keming Mechanical and Electrical Department of Henan Coal Scientific Research Institute) is a holding subsidiary of Henan Coal Scientific Research Institute Co., Ltd. Our company is dedicated to the research and development, production and sales of shotcrete machine, grouting pump, and complementary products. Up to now, we have developed more than 50 kinds of products, covering spraying machines, pumps and other series of products.
