    KHS Series Wet Concrete Shotcrete Machine Piston Type Anti - Stick Technology

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KHS600
    Certification : CE,MA
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 100 Set/Per Month
    Delivery Time : 10~20 Work Day
    • Product Details
    • Company Profile

    KHS Series Wet Concrete Shotcrete Machine Piston Type Anti - Stick Technology

    KHS Series Wet Concrete Shotcrete Machine Piston Type Anti - Stick Technology

    Shotcrete Machine Parameters:

    Items
    Unit
    Technical parameters
    Model
    KHS-6 Shotcrete Machine
    Capacity
    m3/h
    6
    Max. aggregate size
    mm
    15
    Fine aggregates
    Fineness modulus 2.5~3.2
    Addictive ratio of liquid accelerator
    %
    0~7
    Injection pipe ID.
    mm
    57
    Suitable Concrete slump
    mm
    C15~C20:>100; C25~C30:≥150; over C30:≥180
    System air pressure
    MPa
    ≥0.6
    Work air pressure
    MPa
    0.4~0.6
    Air consumption
    m3/min
    >12
    Max. conveying dist.
    m
    30 Horizontally; 20 Vertically
    Dust around
    mg/m3
    <10
    Rebound rate
    %
    ≤20 (on average, standard operation)
    Main motor power
    kw
    7.5
    Dimensions
    (Length×width×height)
    mm
    2100×1100×1450
    Weight
    kg
    1400

    Shotcrete Machine Features:

    1. KHS Series Piston type wet concrete shotcrete machine

    2. KHS Series shotcrete machine adopts the novel rotary-piston feeding mechinism, anti-stick technology, accelerator adding and regulating technology.

    3. KHS-6 has the advantages of resonable design, high efficiency, good property, energy saving, and long service life.

    Shotcrete Machine Application:

    1. KHS-6 Piston type wet concrete shotcrete machine is used for wet concrete shotcrete machine.

    2. KHS-6 Piston type wet concrete shotcrete machine is widely used in mining, water-power engineering, railway, tunnel, metro, bridge, side slope, municipal works and so on.
