    5.5KW 50L/Min Bridges Diesel Cement Grouting Pump

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KBW-50
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 100 Sets/Per Month
    Delivery Time : 5~8 Work Days
    • Product Details
    • Company Profile

    5.5KW 50L/Min Bridges Diesel Cement Grouting Pump

    High quality mortar pump cement grout pump concrete grouting machines

    Grouting Pump Features:

    1. KBW mud pump is widely used for grouting and mud jacking in engineering construction.

    2.KBW mud pump have four gear shifts.Output and drilling depth are adjustable,so it can be used to grout

    cement slurry or equipped with drilling machine.

    3. High quality pump parts, less wearing parts, long service life, low construction cost.

    4. High pump efficiency, less noise and dust, environmental operation, easy maintenance.

    Grouting Pump Application:

    1. KBW-50 piston pump is widely used for cement/mortar grouting in roads, bridges, dams, national defense, mines and other construction projects.

    2. KBW-50 piston pump can be used to grout mortar in prestressed component engineering, vertical and horizontal conveying of mortar in building construction, cement grouting maintenance in sand land, blast furnace, cement pavement, highway and other projects.

    Technical Parameters:

    Model
    KBW-50 grouting pump
    Capacity (L/min)
    50
    Cylinder number (piece)
    1
    Cylinder diameter (mm)
    80
    Piston stroke (mm)
    90
    Pressure (MPa)
    3
    Motor (KW)
    7.5
    Input speed (r/min)
    1440
    Suction hose ID. (mm)
    51
    Discharge hose ID. (mm)
    32
    Maximum suction height (m)
    2
    Triangle belt model
    A1880 (3 grooves)
    Dimensions (L x W x H) (mm)
    1500×550×800
    Weight (kg)
    200
