    Single Piston Type 50L/Min Cement Mortar Grout Pump

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KHB-50/4
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 100 Sets/Per Month
    Delivery Time : 5~8 Work Days
    • Product Details
    • Company Profile

    Single Piston Type 50L/Min Cement Mortar Grout Pump

    High Quality Mortar Pump Cement Grout Pump Concrete Grouting Machines

    Mortar Pump Features:

    1. Single Piston Type Mortar Grout Pump

    2. Small size, light weight, convenient movement.

    3. Compact structure, stable performance, high efficiency, low failure rate.

    4. Easy operation and maintenance, long service life.

    Mortar Pump Application:

    1. KHB mortar pump is used for mortar delivery, fundamental grouting and mending, grout reinforcement of dam, bridge, culvert and tunnel, and delivery of slurry materials, magnetic materials, or other materials.

    2. KHB mortar pump can also be used for wall plastering equipped with spraying gun and compressed air.

    3. It is widely applied in construction engineering, metallurgical industry, chemical industry, infrastructure construction, and national defense engineering etc.

    Suggestion: Cement-sand ratio≥1:3.

    Technical Parameters:

    Model
    KHB-50/4 Mortar Pump
    Capacity
    50L/min
    Max. Pressure
    4MPa
    Work Cylinder
    Single
    Cylinder Dia.
    90mm
    Inlet Dia.
    75mm
    Outlet Dia.
    75mm
    Max. aggregate size
    5mm
    Motor Power
    7.5kW
    Weight
    300kg
    Dimensions (LxWxH)
    1610x1024x900mm

    Single Piston Type 50L/Min Cement Mortar Grout Pump
