    12m3/H Block Making Foam Concrete Pump With Mixer

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KFP-65-40A
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 50 Sets/Per Month
    Delivery Time : 10~15 Work Days
    • Product Details
    • Company Profile

    12m3/H Block Making Foam Concrete Pump With Mixer

    Foam Concrete Block Making Machine For Clc Foam Concrete With Mixer

    Features:

    1. KFP series Concrete Foaming Machine combines feeding machine, water adding device, mixing system, foaming system, delivery system into one machine.

    2. The machine shell is made of high strength and precious steel plate and painted at high temperature of 280℃, ensuring long service life.

    3. Small size,light weight, convenient transport and loading.

    4. Automatic mixing of cement slurry, automatic foaming of foaming agent, automatic delivery of foaming concrete.

    5. Frequency converter control of main pump, and digital display of delivery output.

    6. Even and steady output of cement slurry, uniform density of foam concrete, stable quality.

    7. Delivery system adopts the most advanced hose pumping system, with simple operation, low fault rate, less wearable parts, convenient maintenance,and low cost.

    8. The machine saves production costs and improves economical returns.Compared with similar products, the machine can save 50~100kg cement per cubic meter product.

    9. Professional technician team, excellent after-sales service, perfect technical guide.

    Application:

    1. Take cement and coal ash as raw material to make foam concrete.

    2. Insulating layer, bedding course, floor heating, filling projects of foam concrete roofing.

    3. Other products of foam concrete.

    Technical Parameters:

    Items
    Unit
    KFP-65-40A Foam Concrete Pump
    Rated voltage
    V
    380
    Main motor
    KW
    7.5
    Output
    m3/h
    12
    Vertical delivery dist.
    m
    40
    Horizontal delivery dist.
    m
    120
    Particle size
    mm
    6
    Output pressure
    Mpa
    1.5
    Dimensions (L*W*H)
    mm
    1800*1200*1500
    Main machine weight
    Kg
    1300
    Mixer dimensions
    mm
    1600*800*1300
    Mixer weight
    Kg
    150

    Working principle:

    12m3/H Block Making Foam Concrete Pump With Mixer
