    Hydraulic Motor Hose Pump Concrete Hose Squeeze Peristaltic Pumps

    Ask Lasest Price
    Brand Name : KEMING
    Model Number : KH60B
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T,L/C
    Supply Ability : 100 Sets/Per Month
    Delivery Time : 10~30 Work Days
    • Product Details
    • Company Profile

    Hydraulic Motor Hose Pump Concrete Hose Squeeze Peristaltic Pumps

    Concrete Hose Squeeze Peristaltic Pump for industry application

    Technical Parameters:

    Model
    KH60B Hose Squeeze Pump
    Output
    8~9 m3/h
    Rated pressure
    1.5 MPa
    Rev.
    46 r/min
    Max delivery dist.
    150 m
    Max. particle dia.
    5 mm
    Max. suction dist.
    5 m
    Motor power
    7.5 KW
    Dimension
    1050*1100*980 mm
    Reducer type
    Cycloidal reducer

    Hose Squeeze Pump Features:

    1. No valve operation, no back flow, stable pumping flow, low fault rate.

    2. Free exchange of suction inlet and discharge outlet. When the pump is blocked, reversing pump can discharge the obstruction.

    3. High vacuum, strong self-suction capacity.

    4. Convenient maintenance, less wearable parts (except extruded hose).

    Hose Squeeze Pump Application:

    1. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic materials,crystalline liquid,suspending liquid,emulsion,resin,electroplate liquid,electrolyte solution,precipitate.

    2. Agriculture: phosphate fertilizer,compound fertilizers,thick slurry, precipitated sludge.

    3. Architecture: mortar,plaster,cement paste,soil slurry,silt slurry,lime slurry,foamed concrete, architectural coating, refractory,accelerator,ooze,waste water,sewage and so on.

    4. Mining: gold pulp,tailings,thick pulp,filling materials,underground drainage,adsorbent,slurry, mortar...

    5. Oil industry: drilling fluid,crude oil.

    6. Ceramic industry: ceramic germ plasma, slip glaze, glaze materials.

    7. Paper industry: paper pulp, liquid sulfur.

    8. Cosmetics industry: toothpaste, emulsion, hair conditioner, face cream, facial oil.

    9. Food and Beverage: oil, brew, milk, confiture, salad, syrup, chocolate.

    10. Others: pharmaceutical liquid,radioactive liquid,textile auxiliary,adhesion agent,glue,latex.

    Hydraulic Motor Hose Pump Concrete Hose Squeeze Peristaltic Pumps

    Different configuration the hose pump cost are different:


    First, for peristaltic pumps of the same function and type, flow rate is usually used as a pricing standard. Because if a larger flow rate is to be achieved, the speed of the motor must be increased, so the power of the motor will become larger, including the choice of transformer or DC power supply, which requires additional power, resulting in additional hardware costs, and the price will also be different.


    Second, for peristaltic pumps with the same flow range, different drive modes will have a large price difference. For example, pneumatic explosion-proof and ordinary power transmission, these two drive structures are very different, and the cost will be more different.


    Third, the difference in pump heads will lead to price differences in peristaltic pumps. Due to different materials and different processing methods, the cost of different pump heads will be worse.
